The Aquatouch 1/4" Full Swivel Nozzle Set gives you more precision, more flexibility and the 4 most-used spray angles - all in one smart, entry level kit.

Designed for enthusiasts who want better control without the pro tier price, this set includes four colour coded nozzles (0°, 15°, 25°, 40°) and a built in swivel design to help you hit awkward angles with ease. The swivel action allows the nozzle to pivot freely during use, helping you reach tighter or more awkward spots without adjusting your body position.

These nozzles connect via standard 1/4" quick connect fittings, making them compatible with most aftermarket short guns and lances. The range of spray angles means you're covered for everything from targeted rinsing to wide, soft water coverage for foam removal or final rinses. The red nozzle even gives you flexibility for non automotive cleaning.

Always test your nozzle away from a vehicle after you have plugged it in to the quick connect coupler. Even if you think it has clicked in, it's always good to test it away from a vehicle in case it hasn't 100% locked in.

Orifice Size vs. Spray Angle vs. PSI vs. Waterflow - what does all this mean?

It can sometimes be confusing when looking at your nozzle, figuring out what everything means. We often get asked about the difference between spray angles & orifice size, and what PSI & waterflow even means.

Simply, spray angle is the degree pattern that your nozzle shoots water in. A narrower angle concentrates the water into a tighter stream, while a wider angle spreads it out over a larger area. Spray angle is not connected to your orifice size and doesn’t change the physical hole inside the nozzle - it just changes how that water is distributed onto the surface.

This little hole in the middle of your nozzle is the orifice, and by controlling the size of this hole - you can change your water flow and pressure. If you make the hole bigger, more water will be able to come out, and will reduce your pressure as there is less resistance - alternatively making that hole smaller will create a tighter space, reducing the amount of water than can get through BUT increases the pressure.

Some may think - well I just want to max my waterflow, so ill chuck the largest orifice! But if your pressure washer doesn’t have much power, that could reduce the PSI drastically and even though more water is coming out, your overall cleaning has reduced due to the pressure. We’ve tried to make it super easy for you, by creating a recommended orifice size chart. Simply find your machine’s flow rate down the side, match it to your working pressure across the top, and where the two meet is your recommended orifice size for a balanced setup.

Orifice Chart:

Reading the orifice chart

Simply choose your PSI of your pressure washer or the nearest measurement based on this chart. Then follow the column down to the nearest LPM reading to your pressure washer. Once you hit the reading, follow the row across to the left and you will have your recommended nozzle size.
This is purely based on your pressure washer's max rating meaning choosing an orifice this way will always give you a good amount of water flow, and reduces the risk of choosing a nozzle too small for your unit.

Features:

Swivel Head Design: Allows the nozzle to rotate freely for easier cleaning in tight spots.
Includes 0°, 15°, 25°, and 40° Nozzles: A complete range of spray angles for rinsing and deep cleaning.
Colour Coded for Quick ID: No guessing which nozzle is which.
1/4" Quick Connect: Compatible with most enthusiast level pressure washer setups.
Everyday Use Ready: Ideal for car cleaning, wheel arches, lower panels and general washing and rinsing work.
